Module for AC Converter

  • Order number
    M83200
  • Availability

    Usually on stock
Module for AC signal inputs into pulse outputs

Description

The module M83200 converts AC signal inputs into pulse outputs and provides configurable 5 V outputs.

The module M83200 contains:

  • 4 independent AC signal converters
    • To adapt low amplitude AC (e.g. sinusoidal) signals of various sensors to the counter inputs of Meteo-40 plus data loggers. The sinusoidal signal is converted in a rectangular pulse signal with the same frequency.
  • 2 individually configurable ports with the following configuration options:
    • Current limit to 10 mA (470 Ω)
    • Pull-up resistor 5.1 kΩ with current limit 1 mA
    • Stabilised and ripple-free 5 V output with active current limit 110 mA

Specifications

Module for AC Converter
General
Order Number M83200
Electrical Characteristics (Default Settings)
Supply Voltage (DC) / Quiescent Current Pin: 13
Min: 9 V / 11 mA
Max: 32 V / 16 mA
Ground GND Pin: 15
Configurable Outputs
Output (5 V DC) (ϑ = 25°C) Pin: 14, 16
Min: 5.2 V / 110 mA
Max: 5.8 V / 130 mA
Pull-up Current Limit 1 mA
(Low Current Configuration 5.1 kΩ)		 Pin: 14, 16
Min: 0.97 mA
Max: 1.05 mA
Pull-up Current Limit 10 mA
(High Current Configuration)		 Pin: 14, 16
Typical: 10.5 mA
Max: 11.4 mA
AC Voltage Converters
Input Sensitivity of Converter Pin: 2, 3, 6, 7
Typical: 115 mV
Max: 120 mV
Ground GND Pin: 4, 8
Output Level Low Pin: 9, 10, 11, 12
Value: 0 V
Output Level High Pin: 9, 10, 11, 12
Typical: 5 V
Max: 5.8 V
Operating Temperature -40°C to +75°C
Fuse
Type T0.8A (time lag, slow-blow): 5 × 20 mm
Mechanical & Installation
Housing Dimensions (W × H × D) 22.5 × 110 × 115 mm
Mounting on DIN-rail 35 × 7.5 mm
Terminal Wire Cross Section 0.25 to 1.5 mm²
Terminal Earth
(Recommended)		 1.5 mm²
Wire Length Recommendation Keep wire length as short as possible
