Meteo-40A plus

Description

Convenient collection, storage and processing of weather data

Ammonit’s Meteo-40A plus data logger has been designed to connect Automatic Weather Stations (AWS) in remote areas. The data logger ensures accurate and reliable measurement of the most important meteorological data such as wind speed, wind direction, temperature, humidity, as well as air pressure and solar radiation. Additional sensors, e.g., for precipitation or visibility can be connected.

Ammonit’s Meteo-40A plus offers different input and output channels and can conveniently be extended by implementing additional adapters. Hence, this data logger can efficiently measure all required meteorological and environmental parameters in a campaign.

Ammonit’s Meteo-40A plus is suitable for all climates and remote regions thanks to low power consumption and maintenance work.

Specifications

Meteo-40A plus
General Information
Order Number M41000
Input Channels
Pulse Counters 2 – Precipitation sensor, anemometer
Digital Serial (Status) 4 – Wind vane serial, precipitation monitor
Analog Voltage 12 ± 0.1 V, ± 1 V, ± 10 V, 16 bit – Pyranometers, air pressure sensors, temperature humidity sensors, pot. wind vane
Analog Current 2 ± 1 mA, ± 10 mA, ± 100 mA, 16 bit – Sensors with DC output, e.g., temperature humidity sensor (0 … 20 mA)
RS485 (M) (1) RS485 Master – Smart weather stations, pyranometers
Output Channels
RS485 (S) (1) RS485 Slave – SCADA monitoring software
5V | Switches 4 – Sensor supply, relay for modem, heating supply
Current Source 2 – Pt1000, Pt100
Connectivity
USB (2) USB-A host, (1) USB-B device – PC, modem, USB flash drive, Ethernet, WiFi, GPS, web cam
Ethernet (1) Ethernet – LAN, router, media converter, sat. modem, outdoor camera
Storage Size
Source Data (1-sec data) 1 GB
CSV Data (10-min data) > 50 MB
Display & Keys
Display & Keys (20 x 4) LC display with backlight, five keys
Power & Environment
Power Supply 9 … 36 VDC
Operat. Temperature -40 … +65 °C
Protection (Housing) IP65
Mechanical
Housing Dimensions 260 x 194 x 50 mm
Weight 950 g
Accessories
External modules, plug connector, mounting kit, steel cabinet
